160/215kW Air-Cooled PCS Module 160/215kW Air-Cooled PCS Module

160/215kW Air-Cooled PCS Module

Product Advantages Product Advantages
High-Efficiency Conversion

· Three-level design with efficiency up to 99%

· Intelligent air cooling, no derating at 50°C

Flexible Application

· Support for multi-machine parallel operation and building block-type connection, meeting diverse power requirements

· Modular design for easier installation, operation and maintenance

Safe and Reliable

· IP65 high protection grade with strong environmental adaptability

· Multiple protection measures and built-in fault self-diagnosis function

Grid-Friendly

· Capable of local independent management for peak shaving and valley filling

· Supports multiple fault ride-through capabilities and weak grid applications, ensuring excellent grid adaptability

Technical Specifications Technical Specifications
Model EAMPCS160KHV EAMPCS215KHV
DC Side
Rated Power DC Voltage Operating Range 1000V~1500V
Maximum DC Operating CurrentNumber of DC 180A 261A
Input Channels 1

AC Side (Grid-Connected)
Rated Output Power 160kW 215kW
Maximum Output Power 176kW 236.5kW
Maximum AC Current 154A 206.9A
Rated AC Voltage AC660V
AC Voltage Range 561V~726V
Rated Grid Frequency / Grid Frequency Range 50Hz/45Hz~55Hz
AC Current Harmonics <3% (at rated power)
Power Factor (PF) >99% (at rated power)
Reactive Power Adjustable Range -105%~105%

Efficiency
Maximum Efficiency 99%
Protection
DC Input Protection Equipped
AC Output Protection Equipped
Surge Protection Equipped
Grid Monitoring/Earth Fault Monitoring Equipped
Insulation Detection Equipped
Over-Temp. Protection Equipped

General Parameters
Dimensions (WxHxD) 650x260x800mm 650x285x1100mm
Weight ≤80kg ≤130kg
Isolation Type Non-isolated
Protection Grade IP65 IP66
Operating Temperature Range -30°C~60°C (Derating above 50°C)
Relative Humidity Range 0%~95% (No Condensation)
Cooling Method Intelligent Air Cooling
Maximum Operating Altitude 4000m (Derating above 3000 m)
Communication RS485,CAN
Compliant Standards GB/T34120,GB/T34133, GB/T36547
Grid Support LVRT/HVRT, Active & Reactive Power Control, Power Slope Control
